Storage Steel Silo Roll Forming Machine
Grain Silo Roll Forming Machine – Product Introduction
Our Grain Silo Roll Forming Machine is specially designed for the continuous production of corrugated steel panels used in large-capacity storage silo systems. With advanced forming technology, this machine enables high-speed, precision profiling of galvanized sheets for silo walls, ensuring consistent quality and structural strength.
This equipment is widely used in agriculture, grain storage, feed mills, and other industries where bulk storage is essential. It supports various steel thicknesses and profiles, making it suitable for different silo sizes and customized silo designs.
Automatic Storage Silo And Galvanized Tanks Forming Machine
The line integrates uncoiling, leveling, roll forming, cutting, and stacking functions into a fully automatic system, significantly reducing labor costs and increasing productivity.
Technical Specifications
| Parameter | Specification |
| Material | Galvanized steel (G90–G140), Stainless steel |
| Coil Thickness Range | 0.8 mm – 4.0 mm |
| Coil Width | 1220 mm / 1250 mm (customizable) |
| Forming Speed | 10–20 m/min (adjustable) |
| Roller Material | GCr15 steel with hard chrome coating |
| Number of Roll Stations | 16–24 stations (depending on profile) |
| Main Motor Power | 18–40 kW (based on profile and thickness) |
| Cutting System | Hydraulic post-cutting, blade material: Cr12Mov |
| Control System | Siemens PLC + HMI touchscreen |
| Drive System | Chain or Gearbox drive |
| Decoiler | Manual or hydraulic, 5–10 tons |
| Power Supply | 380V/50Hz/3Ph (customizable) |
| Dimension (L×W×H) | Approx. 15m × 2m × 1.8m (depends on configuration) |
All specifications can be tailored to your specific production needs.
Key Features:
Continuous forming with automatic cutting and stacking
High forming accuracy and low material waste
Compatible with G90/G140 galvanized steel, stainless steel, or pre-coated coil
Heavy-duty frame structure with durable chain drive or gearbox drive
Siemens PLC and touchscreen operation for easy control and recipe switching
Application Fields:
Agricultural Grain Storage
Production of corrugated panels for bolted steel grain silos storing corn, wheat, rice, soybean, and other grains.
Animal Feed Silos
Manufacturing silo walls for poultry, cattle, and livestock feed storage facilities.
Industrial Bulk Storage
Suitable for storage tanks in breweries, distilleries, fertilizer, cement, and chemical industries.
Water and Oil Tanks
Forming panels used for large-capacity liquid storage tanks in remote or rural areas.
Turnkey Silo Manufacturing Projects
Ideal for integrators offering end-to-end grain storage solutions.
Real Customer Cases
- Russia – 2000 Tons Flat-Bottom Silo Project
Client: Agricultural trading company
Machine Supplied: G140 galvanized panel forming line with 24 roll stations
Panel Type: Deep corrugation, 0.8–2.7mm thickness
Production Capacity: 15m/min
Outcome: Client built over 15 silos using this line, praised for panel precision and easy installation.
- Turkey – Feed Mill Silo Project
Client: Animal feed processor
Requirement: Forming line for silos with 8–15m diameter
Machine Specs: Hydraulic decoiler, Cr12Mov blades, 30kW drive motor
Feedback: “Easy to operate, and forming accuracy exceeded expectations. We are considering a second line.”
- India – Galvanized Tank Supplier
Client: Water tank and grain bin manufacturer
Focus: High speed production with minimal coil waste
Machine Advantage: Siemens PLC with language switch, low maintenance design
Result: Daily output exceeded 1,500 panels with less than 1% waste.
Our machine is specially designed to produce corrugated steel panels for grain storage silos and galvanized tanks. We support various panel profiles, thicknesses from 0.8mm to 4.0mm, and custom shapes.
Yes. We provide customized forming roller design and cutting molds based on your silo diameter and panel overlap method. Just send us your silo panel drawing or sample.
This machine is compatible with galvanized steel (GI), aluzinc, zinc-aluminum-magnesium coated steel, and stainless steel, depending on your storage environment.
Yes. Our standard configuration includes PLC control system, touch screen operation, automatic length setting, and hydraulic cutting. Optional automatic stacker and servo feeding are available for higher automation levels.
Standard delivery time is 60–80 working days after deposit and confirmation of technical details. If urgent, we can offer fast-track production in special cases.
Yes. We provide on-site installation and training if needed. For remote clients, we offer video guidance, 3D machine manuals, and online support via Zoom or WhatsApp.
Yes. We can provide a complete solution, including hydraulic decoiler, leveling machine, automatic stacker, and even a cut-to-length or slitting line as per your request.
Absolutely. We have machine running videos and can arrange live video demos or even client factory visit introductions in your region if available.
We offer 1-year warranty for the complete machine (excluding wearing parts). Lifetime support and spare parts supply are available.
